Tube Fiber Laser Cutting Machine
FEATURES
The specialized tube laser cutting machine consists of 7 axes. It can achieve cutting of various tube materials such as round tubes, square tubes, rectangular tubes, and oval tubes. The entire machine is up to 11 meters long, capable of one-time forming and processing of 6-meter long tubes. The equipment is matched with feeding and pulling axes, which can greatly reduce waste of processed remnants. It can cut tubes of various directions and different diameters on the main pipe. Capable of cutting variable-angle bevels or grooves.
Application Industry
Widely used in sports equipment, all kinds of pipe, water pipe, oil pipe, etc, toadapt to all kinds of special shape pipes, such as: round tubes, square tubes, rectangular tube, oval tube,etc,
In the oil industry, for example, oil transportation pipeline is the main way of, and due to the characteristics of the oil itself, caused the high quality requirements of pipeline. Optical fiber laser cutting machine can realize multipleAngle pipe machining precision, meet the demand of oil transportation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Laser Power | 1000W-6000W |
| Tube Length | 6100mm |
| Cutting Thickness | 6mm-12mm |
| Round Tube Dia | φ20-φ330mm |
| Square Tube Side | □14mm-□230mm |
| Positioning Accuracy | ±0.03mm/m |
| Repeatability | ±0.02mm/m |
| Power Supply | AC 380V/50HZ |
| Cooling | hydrocooling |
| Operating Temp | 0℃-40℃ |
| Dimensions | 1160035002400mm |
